| Electrical system | Electric control | CURTIS | |
| The battery | 6 v180ah/only, 12/72 v |
| The motor | 5.5 KW series motor |
| charger | A portable intelligent transformer type charger |
| Charging time | 8 to 10 hours (discharge at a rate of 80%) |
| Technical parameters | Charging the input voltage | 220V |
| Length * width * height | 5000×1500×2350mm | Braking distance | ≤6m |
| Vehicle equipment quality | 1450kg | Rated crew | 14 people |
| The vehicle load | 1000kg | Maximum speed | 25km/h |
| Before and after the wheel track | 1290/1330mm | Maximum gradability | 15% |
| The wheelbase | 2700mm | The minimum bending radius | 6m |
| The minimum clearance from the ground | 150mm | | |
| Body system | The seat | The first row of seats (single seat + high resilience PU, leather,
fabrics, Angle adjustment device, with guide rail, with handrails,
three-point seatbelt, light grey) |
| Three bench seat on the right side (+ high resilience PU, leather
fabrics with armrest, light grey) |
| Two three people on the left side of the bench seat (+ high
resilience PU, leather fabrics with armrest, light grey) |
| The rear bench seat three people (+ high resilience PU leather
fabric, light grey) |
| Car body | Steel frame + glass fiber reinforced plastic shell/ABS engineering
plastics in the whole glass roof |
| instrument | Combination instrument display (including voltage, current, speed,
distance, lighting, commutation signals) before and after |
| Rear view mirror | Manual type outside rearview mirror |
| Lighting and signal | Combination headlights, turn light and combination HouWeiDeng,
brake lights, electric horn and reversing buzzer, luxurious
interior lights |
| The stereo | Car MP3 players, professional speakers |
| switch | Start switch, lighting and wiper switch, in a gear and reversing
switch, warning light buzzer become warped plate switch |
| The door | Electric folding door |
| The frame | Steel frame structure |
| The steering wheel | Polyurethane foam steering wheel |
| The chassis system | Power transmission system | Infinite speed control system |
| Steering system | Machine + electric power steering gear rack type direction |
| The front axle and suspension | Independent suspension + spiral spring, hydraulic damping cylinder |
| The rear axle and suspension | One-piece full floating rear axle, high strength steel plate
spring, hydraulic damping cylinder (12.94) |
| The braking system | Former disc, HouGu type hydraulic brake, dual-circuits power
hydraulic braking, parking brake, brake vacuum booster |
| tire | Front wheel: 12 x 4.5 aluminum alloy wheel hub, giti tire vacuum
155 r12c meridian tire;Rear wheel: 4 j * 13 rims, giti tire vacuum
meridian tyres 155 / R13C |
| Oil paint | Auto level ordinary paint, computer tune paint, professional
spraying equipment |
